Weinig Hydromat 23C 100m/min

Name: Weinig Hydromat 23C 100m/min
Brand: Weinig
Availability: InStock

狀況

二手

位置

Kehra

显示地图

机器数据

機器描述:: 模具

製造商:: Weinig

模型:: Hydromat 23C 100m/min

狀況:: 非常好（已使用）

价格和位置

位置:: Välja 4, 74305 Kehra, Eesti

撥打

优惠详情

產品ID:: A15070570

最後更新:: 於 14.09.2025

描述

Weinig Hydromat 23C with 6 Spindles.
Max width 245mm
Max Thickness 160mm
Separate electrical panel.
Separate remote control panel
Automatic lubrication system for bedplates
Full heavy duty sound enclosure.
15kW feed motor 100m/min

No 1. 7.5kw - Bottom 6000rpm straight jointer prepared
No 2. 11kw - Right 6000rpm straight and profile jointer prepared
No 3. 15kw - Left 6000rpm straight and profile jointer prepared
No 4 . 15kw - Top 6000rpm + Outboard bearing + straight and profile jointer prepared
No 5 . 30kw - Top 6000rpm + Outboard bearing + straight and profile jointer prepared
No 6 . 15kw - Bottom 6000rpm + Outboard bearing + straight and profile jointer prepared
50mm spindles
Ksdpfx Absrn Snmjtedw
Beam 0.55kW
Full documentation included.
Heavy duty sound enclosure.
Possible to supply with hydro tooling if needed.
Possible to supply with full mechanisation if needed.
