数控龙门铣床
WALDRICH SIEGEN V/H – FR - 275/160/250 x 400 (2)

Name: WALDRICH SIEGEN V/H – FR - 275/160/250 x 400 (2)
Brand: WALDRICH SIEGEN
Availability: InStock

製造年份

1982

狀況

二手

位置

Freudenberg

数控龙门铣床 WALDRICH SIEGEN V/H – FR - 275/160/250 x 400 (2)

WALDRICH SIEGEN V/H – FR - 275/160/250 x 400 (2)

显示地图

机器数据

機器描述:: 数控龙门铣床

製造商:: WALDRICH SIEGEN

模型:: V/H – FR - 275/160/250 x 400 (2)

序列號:: 11.239

製造年份:: 1982

狀況:: 良好（使用过）

价格和位置

位置:: Alte Eisenstraße, 57258 Freudenberg, Deutschland

撥打

优惠详情

產品ID:: A3418342

最後更新:: 於 02.12.2024

描述

Distance between columns 2.750 mm, Distance top of table to spindle nose 1.600 mm, fixed cross rail, 2 tables 2.500 x 4.000 mm, coupled 2.500 x 8.700 mm, power 58 kW, revs 1 – 1.800 rpm, base speed 136 rpm, max. torque 3.500 Nm, feeds and rapids 1 – 10.000 mm/min, traverses x y z 9.502 x 5.515 x 1.000 mm, quill movement 500 mm in 4 steps, automatic tool changer with 60 pockets, automatic mounting, 4 x 90° indexing and heel clearance for RAA
Electric and mechanic remanufacturing in 2017 with
• New CNC control SINUMERIK 840 D or at your choice
• New electric cabinet
• New wiring
• New motors for all axis and main spindle
• New measuring system HEIDENHAIN LB 382
Ksdpfx Aedkmiheh Uedw
• Milling carriage general overhauled
• New painting
