Hydraulic C-frame press (punch press)
Year of manufacture: 2025

Capacity: 100 tons at 230 bar

Control / key switch:
1. Manual setup mode without light sensor
2. Automatic (at full speed) with light sensor

Main cylinder: Ø 230 mm
Auxiliary cylinders: 2 x Ø 50 x 30 mm
Auxiliary guide: 2 x Ø 50 mm
Motor: 11 kW – 15 hp
Pump: 16 cc – 23 liters / ASC – Helical gear pump
Speed: Forward 110 mm/sec – Return 200 mm/sec
Pressure phase: 9 mm/sec

Installation height: 500 mm
Stroke length: 400 mm.
Push plate: 750 x 600 mm. – with T-slots
Table top: 750 x 600 mm. – with T-slots
Table height: 850 mm. (Floor to table top edge)
-----
Hydraulic accessories:

Hydraulic control block & accessories: REXROTH
Pressure adjustment via PLC. (20 – 100 tons)
Speed adjustable via PLC.
Air cooler
Feed valve NG.63

Nodpfx Ahewag Rie Aowb
Control accessories:

Siemens S7-1200
Blsbjftg Sgsmmvyhwof
Main control box
Foldable control panel
With side safety door (doors can be moved backwards)
SICK 750 + 150 mm light sensors.
Ruler for adjusting the stroke length
7" PLC screen – Siemens
Movable two-hand control
Alarm indicator for faults (light & sound)
-----

• The press complies with the EN693 Machinery Directive
• Hydraulic two-way valves
• Dual-channel fused control system
• Safety PLC – SICK
• Operating instructions & parts list (German)
• Warranty: 24 months
-----
Oil capacity: 190 liters (Tank volume: 205 liters)

Total weight: approx. 5,500 kg. Overall dimensions: 1300 x 2000 x 2750 mm.

Delivery time: 2 - 3 weeks from stock. Paint finish: Light gray & dark gray

The machine is available immediately in 2 - 3 weeks.

Freight: approx. €2,000 from Konya to Germany
