自动带锯 - 卧式

HBM MBH 128

Technical details:
Kdedpfx Aeu Nig Refusg

cutting diameter: 128 mm
saw band length: 1640 x 13 mm
saw band width: 0,64 mm
cutting range 90 degrees: round: 128 mm
cutting range 90 degrees: flat: 100 x 150 mm
cutting range 45 degrees: round: 90 mm
cutting range 45 degrees: square: 90 x 75 mm
band speed: 24 - 35 - 55 m/min
electrical connection: 220 V / Hz.
total power requirement: 500 Watt
machine weight approx.: 80 kg
dimension machine xH: 0,95 x 0,52 x 1,1 m

The machine is unused-new, in the original box. The band saw can be moved manually.

Application for steel, cast iron and non-ferrous metals.
Workpiece clamping by means of clamping jaws by hand wheel, 1x fixed and once movable, clamping range 165mm, swivel range 60°.
limit stop for length adjustment max. 85mm
