Stöckel FX 80/50 ST 2

Stöckel FX 80/50 ST 2

Surface grinding machine Stöckel FX 80/50 with ST 2 control, year of manufacture 2007, in SUPER condition.
CE-compliant!!
The machine comes from the training workshop of a renowned German mechanical engineering company.

Technical data:

Year of manufacture 2007
Technical data
Clamping area (L x W in mm)
900 x 500
Grindable area (L x W in mm)
800 x 500
Magnetic chuck size max. mm
800 x 500
Grinding wheel dimensions max. mm
300 x 25 x 51
Distance table/spindle center mm
Max. 400
Table longitudinal feed, oscillating m/min
1 – 20
Creep feed mm/min
Bjdpfx Agez Ipk Aevswu
0 – 500
Grinding spindle drive, speed rpm
1900
Power kW
7.5

Machine weight approx.: 4.0 t

Accessories and equipment:

About the machine:

Offered is a surface grinding machine Stöckel FX 80/50 with ST 2 control. This universal surface grinding machine is in very good original condition. It comes from a company where it was only used for training purposes. It features a very easy-to-use control system. A grinding travel of 800 mm in the longitudinal axis and a transverse travel of 500 mm make it suitable for toolmaking, fixture construction, and small-series production. The extensive standard equipment and the easy handling of the machine characterize this series. The stable design of the spindle head and the guide principle with double V-guides in the longitudinal and transverse axes guarantee lasting precision. The intuitive operation of the controls simplifies operation and significantly increases productivity. The guides are regularly lubricated by the central lubrication system. The Stöckel has been mechanically and electrically inspected by us. Take advantage of the opportunity to inspect and test the Stöckel on-site under power.

You can find more surface grinding machines from well-known manufacturers on our website.
