Perfecta 132 TVC

Perfecta 132 TVC Schneidemaschine 73570

Cutting Machine 132 TVC

* Working width: 132 cm
* Mechanical / flywheel knife and hydraulic clamp
* TVC patented touchscreen control with complete graphical interface
* Servo-driven rear table – the fastest in the industry
Csdpfew Ni Unex Aa Sjrh
* Patented overhead control
* Slot-free cutting table
* Knife changing device
* Sturdy one-piece cast iron frame
* Certified to GS, CE, and ISO 9001 quality and safety standards
* TVC touch control
* Programming via color touch display
* Chrome-plated air table and air-assisted side table (left side)
* Includes knife
* Program with color touch monitor
* Pallet lift, precise height adjustment with photo cell
* Digital program with touchscreen
* Air table
* Photo cells
* Large auxiliary tables with air
* Jogging table with air
* Free-standing lift table
* Includes knife holder
* Includes various knives
* Next inspection / machine check due: 02/2027

Specifications TVC/UC: 132
Cutting width (in): 52
Clamp opening (in): 6-1/2
Minimum cut without clamp plate (in): 13/16
Minimum cut with clamp plate (in): 3-1/32
Maximum cutting depth (in): 52
Clamping force (lbs): 560-10,100
Continuous cycles per minute: 44
Drive power (HP): 5.5 or 7.5
Required power (220/208V-3ph): 40 A
Dimensions (W x D x H) (in): 102 x 108 x 64 cm
Weight (lbs): 7,520
Shipping weight (lbs): 9,770

Perfecta is a globally leading manufacturer of highly automated cutting and handling systems for the printing and bookbinding industry. The cutting machines developed in Germany are designed for 24/7 operation and stand out for their high productivity. They are equipped with a flywheel-activated cutting system and hydraulic clamping mechanisms.
