加工中心 - 立式

OPTIMUM OPTImill F 105 CNC

x-travel 550 mm
y-travel 305 mm
z-travel 460 mm
Control Sinumerik 808D adv. Siemens
turning speed range - main spindle 10 - 10.000 min/-1
power capacity - main spindel 11 / 7,5 kW
max. Torque 70 / 48 Nm
tool taper BT 40
table surface area 800 x 320 mm
max. table load 300 kg
T-slots 3x 14 x 100 mm
distance spindle /table 100 - 600 mm
number of toolpositions 12 pos.
tool taper BT 40
max. tool diameter 70 mm
max. tool weight 6,0 kg
change-time tool to tool 7,0 sec
rapid traverse ( X / Y / Z ) 10 m/min
feed speeds max. 10.000 mm/min
repeating accuracy +/- 0,008 mm
positioning accuracy +/- 0,01 mm
total power requirement 15 kVA
weight of the machine ca. 2,9 t
dimensions of the machine ca. 3,5 x 2,5 x 2,4 m
CNC-MachiningCenter Vertical
OPTIMUM - OPTImill F 105 CNC

- SHOW-ROOM-MACHINE
