立式加工中心

Mori Seiki VS10000

Working well
located in Israel
ready for inspect
spindle hours 42000
in very good condition .
Need make METI

NC SYSTEM FS-18IMB(MAPPS 3)
CRT SIZE (INCH) 15 INCH
CUSTOMER FACTORY VOLTAGE (V) 380 V - 480 V
FREQUENCY (HZ) 50 HZ
SETTING UNIT MM
EXPORT TRADE CONTROL ORDER APPLIED
RELOCATED MACHINE SECURITY FUNCTION VALID
PAINT COLOR COOL SILVER
LANGUAGE ON NAME PLATES ENGLISH
LANGUAGE OF INSTRUCTION MANUAL ENGLISH
LANGUAGE OF MACHINE MANUAL ENGLISH
X-AXIS TRAVEL (MM) 2050 MM
Z-AXIS TRAVEL (MM) 600 MM
SPINDLE (SPINDLE 1) SPEED (MIN-1) 12000 MIN-1
SPINDLE HOLE TAPER TAPER NO. 40
SPINDLE HOLE TAPER (#40) 7/24 TAPER #40
GRIP STANDARD (#40) MAS
RETENTION KNOB STANDARD (#40) 90 DEGREE
TOOL STORAGE CAPACITY 40
CHIP CONVEYOR OUTSIDE MACHINE PROVIDED
TYPE OF CHIP CONVEYOR OUTSIDE MACHINE SCRAPER (DRUM FILTER TYPE)
CHIP CONVEYOR INSIDE MACHINE PROVIDED
COOLANT TANK 800 L
COOLANT WATER-SOLUBLE COOLANT
IN-MACHINE WORK MEASURING SYSTEM (SPINDLE) OPTICAL TYPE PROBE SENSOR (RENISHAW)
IN-MACHINE WORK MEASURING SYSTEM (TABLE) ﾀｯﾁｾﾝｻ･MP4(ﾚﾆｼｮｰ)
ADDITIONAL AXIS INTERFACE 付加2軸
Chedpfx Aew Tutwodmjc
MOTOR FOR ADDITIONAL AXIS USER
ROTARY TABLE FOR ADDITIONAL AXIS USER
ROTARY TABLE TYPE 回転軸､傾斜軸共
STEP-DOWN TRANSFORMER PROVIDED
STEP-DOWN TRANSFORMER CABLE PROVIDED
LANGUAGE ON NC SCREEN ENGLISH
LANGUAGE ON PC SCREEN ENGLISH
LANGUAGE ON WARNING SCREEN ENGLISH
LANGUAGE ON MAPPS2/3/4 SCREEN ENGLISH
PART PROGRAM STORAGE (M) 1280 M
NUMBER OF STORED PROGRAMS 63
USER MEMORY AREA(BUILT-IN MAPPS) 50 MB
NUMBER OF TOOL OFFSET PAIRS 64
NUMBER OF WORK COORDINATE SYSTEM PAIRS 6
NUMBER OF CUSTOM MACRO COMMON VARIABLES 82
AI NANO HIGH PRECISION CONTOUR CONTROL PROVIDED
LOAD MONITOR C (SOFT-KEY TYPE)
