Homag Drillteq V-200. Bhx-055

HOMAG DRILLTEQ V-200 Optimat BHX055 Machining Center – used –
Machine purchased in December 2018 / commissioned January 2019

Processing in throughfeed mode,
Ball screws on all axes,
Network card for remote service support,
Saw unit for grooving in X-axis,
Pick-Up type tool changer,
Ite Dibow Hdh Es Ia Asn
Integrated control cabinet

----- Technical Data -----
Minimum workpiece length X: 200 mm,
Minimum workpiece width Y: 70 mm,
Minimum workpiece thickness: 8 mm,
Maximum workpiece length X: 3,050 mm,
Maximum workpiece width Y: 850 mm,
Maximum workpiece thickness: 56 mm,
Machine control software: WOODWOP 8,
Screen diagonal: 24 inches, touch screen,
Main spindle motor power: 10 kW (S6),
Main spindle speed: 1,250 – 24,000 rpm,
Main spindle holder: HSK-F63,
Drilling unit motor power: 2.3 kW,
Number of vertical drilling spindles: 13 pcs,
Number of double horizontal drilling spindles in X-axis: 2 pcs,
Number of double horizontal drilling spindles in Y-axis: 1 pc,
Saw blade diameter: 100 mm,
Kdsdpfx Asxpukgof Asu
Number of tools in changer: 4 pcs,
Vector speed (X-Y): 50 m/min.

Quality information:
- comprehensive basic cleaning
- electrical system checked
- pneumatic system checked
