CORMAK WL2000

A compact device using the FIBER technology, designed for welding many types of metals with precision far exceeding traditional welding methods.

Advanced technological solutions used in the offered welding machine allow to perform high-quality and repeatable welding welds of thin-walled materials and parts without the risk of deformation.
Advantages of a laser welding machine

Easy to use - thanks to the applied solutions and well-thought-out structure, the operator can start working after a short training
Low indirect radiation, when working, it is enough to wear protective glasses to filter strong light,
Welding much faster than with traditional methods, productivity can be increased by up to 3 to 10 times
Concentrated beam: slight structure change due to the small heat-affected area,
The repeatability of the welds, the welding seam is nice, the welds are high strength.
Very thin materials such as 0.5mm stainless steel can be welded.
Option of welding with or without wire.

Technical parameters
Maximum power 2000W
Laser wavelength 1080nm
Depth of penetration (stainless steel 1 m/min) 4.57mm
Depth of penetration (black steel 1 m/min) 3.59mm
Depth of penetration (aluminum 1 m/min) 4.0mm
Depth of penetration (brass 1 m/min) 4.0mm
Welding speed 0-120mm/s
Automatic Wire Feeder Ø 0.8 - 1.6mm
Maximum power consumption ≤6.0kW
Cooling system aqua
Working voltage 400V
Shielding gas consumption 20L/min
Dimensions 600 x 1100 x 1100mm
Weight approx. 185 kg
Dedpfxoizr Rlo Aa Njcn
LATEST GENERATION WELDING HEAD

WOBBLE head;
Automatic wire feeder included;
Adjustable spot size 0-5mm;
The powerful welding head allows many types of beam guidance: -, ○, ◎, ⊙, 8, ∞;
Integrated connections for shielding gases and cooling system,
Interchangeable nozzles allow for welding at different angles,
10 m of optical fiber that connects the head to the source,
Adjustment of welding parameters directly in the head without having to go to the control panel;
Full ergonomics - thanks to the light and flexible design, the head can perform welds even in hard-to-reach places;
Easy to service - quick and easy replacement of the protective lens.

Automatic wire feeder included

The wire feeding system is synchronized with the welding machine software. The task of the feeder is to feed the filling, thanks to which the operator can focus 100% on the work of the head.
Set includes

laser welding machine with built-in cooling system
welding gun with adjustable focus and a set of accessories
Fiber laser source
automatic wire feeder
set of cables
starter kit of nozzles and protective glasses
THICKNESS OF WELDED MATERIALS

Material

WELDER POWER

1000W 1500W 2000W
Stainless steel 0.5-3.0mm 0.5-4.0mm 0.5-5.0mm
Black steel 0.5-2.5mm 0.5-3.5mm 0.5-4.5mm
Galvanized steel 0.5-2.5mm 0.5-3.0mm 0.5-4.0mm
Aluminum 0.5-1.2mm 0.5-1.8mm 0.5-4.0mm
Brass 0.5-1.2mm 0.5-1.8mm 0.5-2.5mm
