CMZ TA-20TY-640

CMZ TA-20TY-640

This 3-axis CMZ TA-20TY-640 horizontal turning machine was manufactured in 2023. It features a maximum cutting diameter of 460 mm, length of 640 mm, and a robust 15 kW spindle capable of 4000 rpm. Includes a Y-axis travel of +70/-50 mm, 15 driven tools with a speed up to 12,000 rpm, and a bar capacity of 66 mm. Consider the opportunity to buy this CMZ TA-20TY-640 horizontal turning machine. Contact us for more information about this machine.

• Maximum cutting diameter – 460 mm
• Maximum cutting length – 640 mm
• Swing over bed – 760 mm
• Swing over saddle – 600 mm
• Y-axis travel – +70 / –50 mm
• Bar capacity – 66 mm
• Chuck size – A2-6"
• C-axis – 0.001°
• Tools number – 15
• Driven tools – 15
• Driven tool power – 8.1 kW
• Driven tool speed – 12 000 rpm
• Tailstock taper – CM3
• Spindle run time – Less than 1500 h (to be confirmed)

Additional equipment

• Chip conveyor – Yes, side discharge
• Tool presetter – Yes
• Automatic tailstock carriage – Yes
• Automatic doors – Yes
• High-pressure pump – 6 bar
• Robot preparation – Yes
• Set of tool holders – Yes
• Spindle cooling system (cooling unit instead of air/oil exchanger) – Yes
Dsdpfx Agex H U Dwsdjcc
• Filtration – 90 µm
