Bendazzoli 4800 CE 型印刷开槽机

Bendazzoli 4800 NBB 186-48

Descriptive Document of the Machinery
“Bendazzoli NBB186/48 CE” Serial No.: 582
Corrugated Cardboard Packaging Production Machine

1. General Description:
- Machine name: Printer Slotter
- Model: NBB186-48
- Manufacturer: Bendazzoli Costruzioni Meccaniche
- Year of Manufacture: 2001
- Year of Mechanical Overhaul: 2025
° Slotter overhauled to as-new condition
° Partial printing unit overhaul (new anilox cylinder and rubber roller, new compensator, new bearings, new lubrication pump, overhauled ink feed pump)
° Partial feeder overhaul (new feeder wheels, new lubrication pump, main motor completely overhauled by CEAR, new CAM bearing)
° Static unit overhauled to as-new condition
Complete sandblasting and repainting of all machine assemblies.
- Year of Partial Electrical Overhaul: 2025
Includes replacement of: sensors / push button panels / onboard cabling / solenoid valves / electrical junction boxes for machine groups.

2. Technical Specifications:
- Dimensions: Length 4800mm; Cylinder Circumference 1860mm
- Speed: Maximum rotation 5,500 cycles/hour under optimal conditions
- Minimum shaft center distance: 450mm
- Sound pressure level (feeding area): 85dB (A)
- Sound pressure level (delivery area): 82dB (A)
- Electrical characteristics: Supply 400Vac Three-phase 3P+PE
Nominal Power: 70KW
Power Consumption: 57KW
Nominal Current: 102A
Operating Current: 82A
- Production speed: approximately 5,000 boxes/hour in sync mode, approximately 2,500 boxes/hour in extended mode

3. Main Components:
- Cronofit Feeder Table Group with automatic positioning of side guides and bundle support gate.
- Printing Unit Group with automatic print presetting
- Slotter Unit Group with extending and automatic presetting (knife heads) and carton height adjustment
- Static Unit Group

4. Safety:
- The machine is fitted with protective guards on all moving parts, equipped with sensors to detect guard opening.
- Each machine group is provided with an emergency stop mushroom button and a rope pull switch to instantly halt group movements.

5. Electrical Equipment:
- Main electrical cabinet housing all control and power distribution components
- Operator control desk/console complete with touch screen panel

Kljdpfx Abeyifdvswon
6. Components not included, for possible installation:
- Cable tray and optional accessories
- Command and power cables between cabinet/console/machine assemblies
- Network bus cables
-Price Negotiable

Note: Possibility to purchase a Die-Cutter and Stacker (year 2008, requires overhaul)
